GIGABYTE X870 GAMING WIFI6

GIGABYTE X870 GAMING WIFI6 motherboard is designed to offer excellent performance for high-end gaming and professional computing. Here's an overview of the motherboard's key features and specifications:

Key Features:

• AMD Socket AM5: Supports AMD Ryzen™ 9000, 8000, and 7000 Series Processors.

• Digital Twin 8+2+2 Phases VRM: Provides stable power delivery for overclocking and demanding applications.

• Dual Channel DDR5: 4 DIMM slots supporting up to 256 GB of DDR5 memory, with support for AMD EXPO™ and XMP memory profiles for easy overclocking.

• WIFI EZ-Plug: Simplifies the Wi-Fi antenna installation process for a hassle-free setup.

• EZ-Latch Plus: PCIe and M.2 slots with screwless designs for easy installation and upgrades.

• Ultra-Fast Storage: 3 M.2 slots, including 1 PCIe 5.0 x4 slot, for blazing-fast SSD performance.

• Efficient Thermal Management: VRM Thermal Armor and M.2 Thermal Guard help maintain optimal temperatures during heavy workloads.

• Networking: 2.5GbE LAN and Wi-Fi 6 (802.11ax) with Bluetooth 5.3 for fast and reliable networking.

• Extended Connectivity: Dual USB4 Type-C ports (with DisplayPort support), HDMI, and multiple USB ports.

CPU Support:

• Socket AM5: Compatible with AMD Ryzen™ 9000, 8000, and 7000 Series processors.

Memory Support:

• DDR5 Memory: Supports overclocked speeds (up to DDR5 8200) with a total capacity of 256 GB (64 GB per DIMM).

• Dual Channel Architecture: For improved memory bandwidth.

• Memory Profiles: Supports AMD EXPO™ and XMP for overclocking and memory optimization.

Onboard Graphics:

• Integrated AMD Radeon™ Graphics (based on CPU model).

• Video Outputs:

  • 1 x HDMI port (up to 4096x2160@60Hz).

  • 2 x USB4® Type-C® ports supporting DisplayPort 1.4 (up to 3840x2160@240Hz).

Audio:

• Realtek® Audio CODEC: High-definition audio with 2/4/5.1/7.1-channel output.

• HDMI 2.1: Supports HDR and high-definition audio/video output.

Networking:

• Realtek® 2.5GbE LAN: For fast wired networking at speeds up to 2.5 Gbps.

• Wi-Fi 6 (802.11ax): With support for 2.4/5 GHz bands, Bluetooth 5.3, and a maximum wireless speed of 80 MHz.

Expansion Slots:

• 1 x PCIe 5.0 x16 Slot: Supports high-speed graphics cards with AMD Ryzen™ 9000/7000 processors.

• 2 x PCIe 3.0 x1 Slots: For additional expansion cards like USB controllers or sound cards.

Storage:

• M.2 Slots:

  • 1 x PCIe 5.0 x4 (for next-gen high-speed SSDs).

  • 2 x PCIe 4.0 x4/x2 slots.

• 4 x SATA 6Gb/s: Additional storage options for HDDs/SSDs.

• RAID Support: RAID 0, RAID 1, RAID 5, and RAID 10 (depending on the storage and CPU).

USB Ports:

• 2 x USB4® Type-C® Ports (back panel): With DisplayPort and USB4 support.

• 1 x USB 3.2 Gen 2 Type-A Port (red, back panel).

• 1 x USB 3.2 Gen 1 Port (back panel).

• Multiple Internal USB Headers for additional connectivity options.

Thermal and Power Management:

• VRM Thermal Armor: Helps keep the voltage regulation modules cool under heavy loads.

• M.2 Thermal Guard: Ensures SSDs operate at optimal temperatures.

• Fan Speed Control: Monitors and adjusts fan speeds for efficient cooling, including support for water cooling setups.

Internal I/O Connectors:

• 24-pin ATX Main Power Connector.

• 8-pin and 4-pin ATX 12V Power Connectors.

• CPU and System Fan Headers: For effective cooling.

• RGB/LED Headers: 3 addressable RGB Gen2 headers and 1 regular RGB header.

BIOS and Software:

• Q-Flash & Q-Flash Plus: For easy BIOS updates.

• Smart Backup: Ensures your system settings are backed up.

• Bundled Software: Includes Norton® Internet Security and LAN bandwidth management software.

Operating System Support:

• Windows 11 64-bit and Windows 10 64-bit.

Form Factor:

• ATX Form Factor: 30.5 cm x 24.4 cm, providing plenty of room for components and expansion.
